Creating TrendLines

Creating TrendLines at Design Time

TrendLines can be created at design time using the TrendLine Collection Editor. Using the collection editor, you may add, modify and remove trend lines. For more information on the TrendLine Collection Editor, see TrendLine Collection Editor.

Creating TrendLines Programmatically

To create a TrendLine programmatically, create instance of TrendLine object and set its properties. The TrendLine can be created using its constructor or AddNewTrendLine.TrendLinesCollection() method of TrendLinesCollection.

The following code adds a red TrendLine to ChartGroup(0) of the Chart:

To write code in Visual Basic

Visual Basic	Copy Code
' create trend line Dim tl As C1.Win.C1Chart.TrendLine = New C1.Win.C1Chart.TrendLine() ' first data series tl.SeriesIndex = 0 ' set line color and thickness tl.LineStyle.Color = Color.Red tl.LineStyle.Thickness = 2 ' show formula in legend tl.Text = "{#FORMULA}" ' add trend to the chart c1Chart1.ChartGroups(0).ChartData.TrendsList.Add(tl)

To write code in C#

C#	Copy Code
// create trend line C1.Win.C1Chart.TrendLine tl = new C1.Win.C1Chart.TrendLine(); // first data series tl.SeriesIndex = 0; // set line color and thickness tl.LineStyle.Color = Color.Red; tl.LineStyle.Thickness = 2; // show formula in legend tl.Text = "{#FORMULA}"; // add trend to the chart c1Chart1.ChartGroups[0].ChartData.TrendsList.Add( tl);

This topic illustrates the following:

The red trend line connects the first and last data points.
