Properties in the C1WebToolBarItem Collection Editor

The C1WebToolBarItem Collection Editor allows you to view and modify your items. You can select from three different types of items in the Add button drop-down list: C1WebTopicBarItem, C1WebContentItem, and C1WebSeparator.

You can access the C1WebToolBarItem Collection Editor by clicking on the ellipsis button in the Collections property of the C1WebToolBarGroup Collection Editor. The editor below includes the collection of properties for C1WebTopicBar's items.

C1WebToolBarItem Properties

The following properties for the Link item type are available for the user in the C1WebToolBarItem Collection Editor:

· C1WebToolBarItem Appearance Properties

The appearance properties change the appearance of the toolbar item. The appearance properties and their functions are listed below:

Property	Description
IconBarWidth	Sets or returns the width of the icon bar drawn on the side of the groups.
ItemPadding	Space between item's border and content.
NavigateUrl	Gets or sets the URL link once the hyperlink is clicked in the toolbar item.
Text	Gets or sets the text displayed for the item in the control.
ToolTip	Gets or sets the ToolTip text displayed when the mouse pointer rests over the item.

· C1WebToolBarItem Behavior Properties

The behavior properties change the item's behavior. The behavior properties and their functions are listed below:

Property	Description
CausesValidation	Determines whether validation is performed when the item is clicked.
ClientScripts	Collection of client-side scripts associated with the item.
CommandArgument	Gets or sets an optional parameter passed to the ItemClick and ItemSelected events of the C1WebToolBar component along with the associated CommandName.
CommandName	Gets or sets the command name associated with the C1WebToolBarItem passed to the ItemClick and ItemSelected events of the C1WebToolBar component.
DropDownContextMenuId	Specifies the ID of the linked C1WebMenu in Custom context mode for the drop-down button.
Enabled	Gets or sets a value indicating whether the item is enabled.
HasDropDownButton	Specifies whether or not the toolbar item has a drop-down button in the left side.
Selected	Gets or sets a value indicating whether the current item is selected.
Target	Gets or sets the target window or frame to display the Web page content linked to when the C1WebLinkItem is clicked.
Visible	Gets or sets a value indicating whether or not the item is visible.
WrapText	Gets or sets a value that indicates whether the item's text is wrapped.
KeyboardShortcut	String representing keyboard shortcut to perform the action of this item.

· C1WebToolBarItem Style Properties

The style properties change the item's style. The style properties and their functions are listed below:

Property	Description
DisabledItemStyle	Style for the item in disabled state.
ItemStyle	Style for the item.
MouseOverItemStyle	Style for the item when the mouse hovers over it.
MouseOverSelectedItemStyle	Style for the item when the mouse hovers over the selected item.
SelectedItemStyle	Default style for the child items in the selected state.

When a Content item is selected in the tree view of the C1WebToolBarItem Collection Editor, it contains the following types of properties:

· C1WebContentItem Appearance Properties

The properties specify C1WebTreeView content items' appearance. The link items properties and their description are listed below:

Property	Description
ItemPadding	Space between the item's border and content.

· C1WebContentItem Style Properties

The properties specify the C1WebTreeView content items' Style properties. The Content Items' properties and their description are listed below:

Property	Description
BackColor	Background color of the controls applied with this style.
BackImageUrl	The URL of the background image.
BorderColor	Border color of the controls applied with this style.
BorderStyle	Style of the border of controls applied with this style.
BorderWidth	Thickness of the border around the controls applied with this style.
CssClass	CSS class name applied to the user of this style.
Font	The font used for text in the controls applied with this style.
ForeColor	The foreground color of the controls applied with this style.
Height	The height of the controls applied with this style.
ImageTextSpacing	Specifies the spacing between the item's image and text.
ImageUrl	The URL of the image to use in an icon place.
ItemImagePosition	Specifies the position of an image relative to the item's text.
LeftBorderImageUrl	The URL of the left border image.
RightBorderImageUrl	The URL of the right border image.
Width	The width of the controls applied with this style.

C1WebSeparator Properties

The following properties for the C1WebSeparator item type are available for the user in the C1WebToolBarItem Collection Editor:

· C1WebSeparator Style Properties

The style property changes the item's style. The style property and its function are listed below:

Property	Description
BackColor	Background color of the controls applied with this style.
BackImageSize	Height for horizontal or width for vertical separators.
BackImageUrl	Image url for the separator image.
BorderColor	Border color of the controls applied with this style.
BorderStyle	Style of the border of controls applied with this style.
BorderWidth	Thickness of the border around the controls applied with this style.
CssClass	CSS class name applied to the user of this style.
PaddingBottom	Bottom padding for the separator image.
PaddingLeft	Left padding for the separator image.
PaddingRight	Right padding for the separator image.
PaddingTop	Top padding for the separator image.
